Optimize the coolant supply and extend the lifespan of your CNC machine.

Accustrip’s High Pressure & Filtration Unit provides a constantly clean and tempered machine reservoir by continuously rinsing and sucking the secondary particles out of the reservoir and into the automatic filtering process resulting in cost savings.

With Accustrip’s High Pressure Unit (HPU), you get filtering and high pressure in one unit. It includes everything required for an optimized coolant supply to your process line. Furthermore, it is easy to implement to your existing line-up.

High pressure unit (hpu)

2 in 1 HPU unit - Filtering and High Pressures

High pressure for any tool in your M-library

Plug and Produce for any CNC machine

Self-cleaning filters which filters all materials

Flow-rate: 10 – 160 litres/min. (flow up to 600 L/min )

Pressure range: 10 – 150 Bar standard.

Connection

Connect the coolant hoses, a power cable, and the pressured air supply and you are up and running in no time. The unique construction makes it easy to integrate the HPU unit with both new and existing systems. The HPU unit can be delivered with an interface to the CNC machine, which allows you full control of the HPU.


Simple & efficient

The Accustrip HPU includes a standard PLC system to control the output pressure. The system lets the pump run at the same speed during operation and tuning or alteration of the pressure is controlled via a quick response valve installed in the by-pass line and a pressure transmitter installed in the main feeding line.



1 %
Cleaning

Reduce cleaning
procedures by 95%

1 %
Tools

Increase tooling life by 20%

1 %
Coolant

Reduce coolant emulsion by 70%

1 %
Protection

Protect spindel,
tools & parts by 99%

Want to know more? Check out our HPU leaflet.
